Paper Ring Crush Tester / Edge Crush Tester

Name: Paper Ring Crush Tester / Edge Crush Tester
Brand: PAP-TECH ENGINEERS & ASSOCIATES
Price: 150000.0 INR
Availability: InStock

Price 150000.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

Paper Ring Crush Tester / Edge Crush Tester Specification

Application
Paper, Board, Corrugated Box Strength Testing

Operating Voltage
230V AC, Single Phase

Frequency
50 Hz

Max Height
200 mm specimen height

Port Size
Standard 8 mm for air supply

Power Supply
AC

Automation Grade
Semi Automatic

Temperature
10C to 40C (Operating)

Humidity
20% - 90% RH (Recommended for operation)

Hardness
Hardened steel platens

Usage
Industrial

Test Range
0 - 1000 N

Mounting Type
Table Top

Features
Peak hold, Overload protection, Auto return

Product Type
Paper Ring Crush Tester / Edge Crush Tester

Equipment Type
Ring Crush / Edge Crush Tester

Number of Specimens
1

Measuring Range
0 - 1000 N

Response Time
Instantaneous (1 second)

Accuracy
1% of full scale

Resolution
1 N

Display Type
Digital LCD Display

Interface Type
RS232 / USB (optional)

Capacity
1000 N (or as specified)

Machine Weight
Approx. 40 kg

Test Speed
12.5 mm/min

Test Width
100 mm

Test Stroke
Up to 20 mm

Control Mode
DIGITAL

Calibration
Supplied with calibration certificate

Service Support
Available onsite/offsite as required

Safety Features
Overload and overtravel protection

Clamp Material
Precision ground, anti-corrosive steel

Software
PC connectivity with result analysis (optional)

Data Storage
Up to 1000 test results

Frame Material
Mild Steel with powder coated finish

Operating Environment
Dust free, vibration-free room

Paper Ring Crush Tester / Edge Crush Tester Trade Information

Minimum Order Quantity
1 Piece

FOB Port
DELHI

Payment Terms
Others

Supply Ability
1 Piece Per Week

Delivery Time
10 Days

Packaging Details
packaging charges will be 5 % extra on the given price

Main Export Market(s)
Asia, Australia, North America, Western Europe, Middle East, Africa, Central America, South America, Eastern Europe

Main Domestic Market
All India

About Paper Ring Crush Tester / Edge Crush Tester

The Ring Crush Tester is a specialized instrument designed to determine the crushing strength of paper, paperboard, and corrugated board. It is widely used in quality control labs to evaluate the material's ability to resist compressive forces applied in the edgewise direction. This test is essential for assessing the strength and durability of materials used in packaging applications.

Applications:

Testing the ring crush strength of paper and board.
Measuring the strength of corrugated boards, solid fiberboards, and paperboard for packaging applications.
Ensuring compliance with international testing standards.

Salient Features:

High Accuracy: Provides precise measurements of compressive strength.
User-Friendly Design: Easy to operate with intuitive controls and a clear digital display.
Sturdy Construction: Designed to maintain consistent parallelism of test plates for reliable results.
Versatility: Capable of performing RCT (Ring Crush Test), ECT (Edge Crush Test), and FCT (Flat Crush Test).
Microprocessor-Based Models: Advanced versions offer data storage, connectivity to computers, and printers for analysis and record-keeping.

Robust Construction for Reliable Testing

Featuring a mild steel frame with powder coated finish, the tester ensures durability even in demanding industrial settings. Precision ground, anti-corrosive clamps and hardened steel platens provide consistent and repeatable crush resistance measurements for papers, boards, and corrugated boxes.

Advanced Safety and Data Management

To safeguard both operator and equipment, it incorporates overload and overtravel protection. The digital system can store up to 1000 test records and offers instant results, with peak hold and auto return features for ease of operation and monitoring.

Seamless Operation & Analysis

Designed for dust-free, vibration-free environments, the tester is compatible with optional PC software for in-depth data analysis. Calibration is straightforward with the included certificate, and comprehensive onsite or offsite service support is available to ensure smooth operation.

FAQ's of Paper Ring Crush Tester / Edge Crush Tester:

Q: How is the paper ring crush tester calibrated and maintained?

A: The tester is supplied with a calibration certificate, verifying accuracy as per standards. Regular calibration checks are recommended to maintain the 1% full-scale accuracy. Maintenance should be performed in a dust-free, vibration-free room to ensure the longevity of the equipment.

Q: What is the process for conducting a crush resistance test using this equipment?

A: To perform a test, mount a single specimen in the precision clamp, set parameters using the digital controls, and initiate the test. The machine automatically applies a force up to 1000 N, displaying the instantaneous result on the LCD and optionally storing the data for later analysis.

Q: When should the stored test results be transferred for analysis, and how does the connectivity work?

A: Results can be transferred at any time if software and PC connectivity (RS232 or USB) are enabled. The data storage capacity of 1000 tests allows users to review or download data for comprehensive analysis as required by quality control processes.

Q: Where should the ring crush/edge crush tester be installed for optimal performance?

A: Install the tester in a dust-free and vibration-free room, maintaining 20%-90% RH and a temperature between 10C and 40C. Such an environment ensures accurate readings and optimal instrument performance.

Q: Who benefits from using this equipment, and what are the primary applications?

A: Manufacturers, exporters, importers, service providers, and quality control professionals within paper, board, and corrugated packaging industries benefit from improved product strength validation and compliance. The tester is essential for determining crush resistance of various paper-based materials.

Q: What safety features does the equipment offer during operation?

A: The device is equipped with both overload and overtravel protection to prevent damage and ensure safe usage for operators throughout the testing process.

Q: How does the tester improve laboratory efficiency and data management?

A: Its digital design offers peak hold, auto return, and stores up to 1000 results instantly, reducing manual record-keeping and speeding up analysis with optional PC connectivity. These features streamline operations for industrial testing labs.
